# 160273 $179.99
The price listed is for 1 ramp. Each ramp is sold separately. This ramp is used on most C4 and C5 trailers.Each ramp is rated for 10,000 lbsThese ramps will have the hook welded on the inside edge of the main channels60" long13" wide3" channel supportsBlack Powder Coat59 lbs eachSold individually***This ramp is very similar to the 160205. The only difference is the width. This one is just about an inch wider. They may not fit well in a ramp pocket that was built for the narrower ramp.
# 160009 $270.00
The price listed is for 1 ramp. Each ramp is sold separately. 16” x 77” ramps for 2014 and newer PJ Dump Trailers. This ramp is used on most PJ dump models, D7, DL, DJ, D8, D9, DS, DN, DM, DH, D3 Each ramp is rated for 5,000 lbs 77" long 16" wide 3" channel supports Black Powder Coat 85 lbs each
# 160205 $169.95
The price listed is for 1 ramp. Each ramp is sold separately. This ramp is used on most CC, B5, B6, B8, and C8 trailers.Each ramp is rated for 10,000 lbsThese ramps will have the hook welded on the outside edge of the main channels60" long12" wide3" channel supportsBlack Powder Coat59 lbs eachSold individually***This ramp is very similar to the 160273. The only difference is the width is about 1" narrower. If you attempt to put this ramp in the ramp pocket that was originally built for a 160273 it may fall out.
# 160286 $129.99
The price listed is for 1 ramp. Each ramp is sold separately. This is the ramp that is used on U6, U7, and U8 utilities that slide into the side rails. 51" long 9.75" wide Black Powder Coat Always check the length before ordering. Some trailers have different lengths 61", 51", or 41" are available. This depends on the length of the trailer and number of axles on the trailer.
# 160254 $643.50
The price listed is for 1 ramp. Each ramp is sold separately. This is the same ramp as our 160244 but it is 80" long. (160244 is 60" long) Used for loading low clearance vehicles that require a longer rampIt has adjustable height support knee to reduce trailer tip up during loading.Used on CC,C8, B6, B8 and other equipment trailers16" wide and 80" long 3" channelMounts to 1.5" dia. ramprodUses 180412 or 180413 helper springs. 7000lb weight capacitySupport leg adjusts from 12" to 16" tall.
# 160244 $586.00
The price listed is for 1 ramp. Each ramp is sold separately. Stand up ramp with the adjustable height support leg Used on CC,C8, B6, B8 and other equipment trailers 16" wide and 60" long 3" channel Mounts to 1.5" dia. ramprod Uses 180412 or 180413 helper springs . Support leg adjusts from 12" to 16" tall. 7,000lb weight capacity This ramp is typically used on straight deck trailer and will bottom out if used on a dovetail trailer
# 161085 $736.00
Bi-fold 83" Reg. side Black Gate for U8 Trailer Expanded metal gate folds in center to reduce wind drag and increase fuel economy Improves rear visibility Available with a straight, 2 foot, or 4 foot dovetail Ramp gate is spring assisted for easy lifting and lowering Built from square tube, angle, and channel Available in 60", 77", and 83" widths The bi-fold gate can be retrofitted to most PJ utility trailers Available on C4, C5, U6, U7, and U8 Models Includes 7.5" hinge pin 180176 x 2 and lynch pin 180124 x 2 Extended: 4'. Folded: 2' Weight: 175lbs
